Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Kingeye
  • Model Number: KI-A032
  • Usage: security protection accessories
  • Product name: Two Beams Active Infrared Detector, Perimeter motion sensor for fences
  • color: white
  • certification: CE
  • type: multi-beam
  • wireless frequency: 433mhz
  • chip: 1527 330k
  • signal distance: 100m outdoor
  • unit weight: 1kg
  • Warranty: 2 Years

Packaging & Delivery

Packaging Details: 1 set/ box;10 sets/carton
Delivery Detail: 3 days for MOQ





Product Name:  Two Beams Active Infrared Detector, Perimeter motion sensor for fences



Description:

It is the best equipment to protect your house safe. It can be installed in the yard,
building surrounding or two sides of the yard door, especially inner balcony to
substitute metal structure. It gives you beautiful feeling .It will alarm at once and dial the pre-set alarm numbers.
1, The emitting bundle is shutoff by the object diameter of 20cm
2, The working elements as bellows: Several unvisible defense bundles from the
remitters forms protection network. The buzzer of the receiver will hoot once
any bundle is shut off for over 40ms and then the alarm host will send out the radio
alarm. The remitting will think it is normal and will not send out the alarm signal to
alarm host when a small animal such as bird, dove jump the protection area because
they only shut off one infrared remitting bundle





Features:
1, Dormant defense and protection baluster makes the burglar found in no any sense.
2, Complete defense ability: It can detect any activation of the burglar
3, Good interfere proof characteristics: It wound not occur wrong report for
  the insect and other mall animal.
4, Strict anti-destroy ability: It will output the alarm signal once the power or cable are cut.



Technical Index:
1, Power voltage: +12VDC
2,Current: 50mA remitting, 60mA receiving, 45mA alarm
3,Protection area: 30m inner, 10-25m outside.
4,Maximum remitting bundle distance: 36m
5,Remitting bundle numbers: 2
6,The width of the remitting bundle: 100mm
7,Detecting type: Single bundle, complete shutoff trigger
8,Trigger time: 40ms
9,Workign temperature: -10 ~ +50°C, relative humidity: ≤95%
10,Alarm output: Radio remitting output.
11, Alarm type: Locale Alarm and dial the telephone automatically and send out the
DTMF and broadcasting record
12, The remitter weight exclusive battery: 500g
13, The receiver weight exclusive: 500g
